E5EN series 48*96mm digital temperature controllers

Illustrated submodels
Mouse over to zoom in
Price: US $8.24 / piece
Model number: E5EN-R-K399
Product name: Digital temperature controller
Output type:
Electromagnetic relaySSR
Input type:
K
Measuring range:
0-399℃0-999℃
View DetailsPrice for the selected variant only, shipping excluded.
Click to check freight or place an order.
Product description
▇ Model number and parameters
Model numberExternal dimensionsPerforation dimensionsOnline store:
E5EN48x96x110 mm45 10x92 10 mmVisiting...
▇ E5EN digital temperature controller model number legend
E5EN
Parent Model Number
Output type
-R: Electromagnetic relay
-SR: SSR
Input type
-K: K
Measuring range
399: 0-399℃
999: 0-999℃
▇ General
Model number E5EN-YR40K
Accuracy ±1%F.S±1℃
Supply voltage 220Vac, 50/60 Hz
Input type K
Output type Mechanical Relay, SSR (not in one product, need to select)
Power consumption Less than 5 VA
Control method ON/OFF Control
Setting method Dial switch
Indication method 7-segment 3-digital display
Alarms No alarm
Operating humidity 0 to 50 ℃ (32 to 122 ℉)
Alias name 85% RH max, non-condensing
▇ Output type and description
Electromagnetic relay Contact rating: 3A at 250Vac
Solid state relay Contact rating can be selected, order separately (Single phase 40A, Three phase 40A)
▇ Input type and measuring range
K 0-999 ℃ (Bolt, Press spring, Ring, M12 probe, M8 probe, Flexible probe, Armor high temperature resistant, Customized thread probe)
▇ E5EN digital temperature controller submodels
No Model Number Output Type Input Type Measuring Range MOQ Unit Price
1 E5EN-R-K399 Electromagnetic relay K 0-399℃ 1 US $8.24
2 E5EN-R-K999 Electromagnetic relay K 0-999℃ 1 US $8.24
3 E5EN-SR-K399 SSR K 0-399℃ 1 US $10.79
4 E5EN-SR-K999 SSR K 0-999℃ 1 US $11.22
