ASY-2D series on delay DPDT digital time relays
Main child models
Price: US $6.04 / piece
Model number: ASY-2D-BN220VAC-9.9S
Product name: Time relay
Supply voltage:
220VACProduct description
▇ Contact form and delay time
| Model number | Contact form | Delay time | Online store: |
| ASY-2D | On-delay DPDT | 9.9s/99s/9.9min/99min | Visiting... |
| ASY-3D | On-delay DPDT | 99.9s/999s/99.9min/999min | US $4.98 - 5.17/ pieceOrder (16) |
| ASY-3SM | On-delay DPDT | 0.1s-999min | US $7.16 - 7.32/ pieceOrder (2) |
▇ ASY-2D time relay model number legend
ASY-2D
Parent Model Number
▇ General
| Model number | ASY |
| Supply voltage | 12, 24, 36, 48, 110, 220 or 380 Vac, 50/60 Hz; 12 or 24 Vdc |
| Tolerance | -15% ... 10% at AC and -10% ... 10% at DC of rated supply voltage |
| Power consumption | 3W max |
| Setting method | Dial switch |
| Indication method | 8-segment digital display with LED |
| External dimensions | 90x58x88 |
| Perforate dimensions | 63 10x51 10 mm |
| Contact rating | 5A@250Vac, 5A@28Vdc |
| Repeat accuracy | ±0.3%, ±0.05 sec |
| Setting error | ±0.5%, ±0.05 sec |
| Termination | 8 pins |
| Matched socket | PF083A |
| Mechanical life | 1x106 |
| Electrical life | 1x105 |
| Operating temperature | -10 to 55 ℃ (14 to 131 ℉) |
| Operating humidity | 45-80% RH max, non-condensing |
| Alias name | ASY digital timer |
▇ ASY-2D time relay child models
| No | Model Number | Case Color | Socket | Supply Voltage | Delay Time | MOQ | Unit Price |
| 1 | ASY-2D-BN220VAC-9.9S | Black | Without socket | 220VAC | 9.9s | 1 | US $6.04 |
| 2 | ASY-2D-BN220VAC-99S | Black | Without socket | 220VAC | 99s | 1 | US $6.04 |
| 3 | ASY-2D-BN220VAC-9.9M | Black | Without socket | 220VAC | 9.9min | 1 | US $6.04 |
| 4 | ASY-2D-BN220VAC-99M | Black | Without socket | 220VAC | 99min | 1 | US $6.04 |
| 5 | ASY-2D-BS220VAC-9.9S | Black | With socket | 220VAC | 9.9s | 1 | US $6.6 |
| 6 | ASY-2D-BS220VAC-99S | Black | With socket | 220VAC | 99s | 1 | US $6.6 |
| 7 | ASY-2D-BS220VAC-9.9M | Black | With socket | 220VAC | 9.9min | 1 | US $6.6 |
| 8 | ASY-2D-BS220VAC-99M | Black | With socket | 220VAC | 99min | 1 | US $6.6 |
| 9 | ASY-2D-WN220VAC-9.9S | White | Without socket | 220VAC | 9.9s | 1 | US $6.6 |
| 10 | ASY-2D-WN220VAC-99S | White | Without socket | 220VAC | 99s | 1 | US $6.6 |
| 11 | ASY-2D-WN220VAC-9.9M | White | Without socket | 220VAC | 9.9min | 1 | US $6.6 |
| 12 | ASY-2D-WN220VAC-99M | White | Without socket | 220VAC | 99min | 1 | US $6.6 |
| 13 | ASY-2D-WS220VAC-9.9S | White | With socket | 220VAC | 9.9s | 1 | US $6.83 |
| 14 | ASY-2D-WS220VAC-99S | White | With socket | 220VAC | 99s | 1 | US $6.83 |
| 15 | ASY-2D-WS220VAC-9.9M | White | With socket | 220VAC | 9.9min | 1 | US $6.83 |
| 16 | ASY-2D-WS220VAC-99M | White | With socket | 220VAC | 99min | 1 | US $6.83 |
