Product features
Mouse over to zoom in
XB2-BD21 22mm self-lock ON - OFF turn push button switch SPST pushbutton
Price: US $0.92 / piece
Model number: XB2-BD21
Product name: Push button
Deliver to:
Shipping:
US $6.86via
Estimated Delivery Time: 9-15 days
Quantity:
Total price:US $7.78
Buy Now
Add to Cart
Inquire
Payment:
PayPal/Credit CardWESTERN UNIONBANK TRANSFER
Product description
▇ Model number and parameters
Model numberHead shapeAction methodContact formContact ratingColor codeLamp voltageOnline store:
XB2-BA21RoundReset(ON)-OFF3A@240VAC     US $0.69/ pieceOrder
XB2-BA31RoundReset(ON)-OFF3A@240VAC     US $1.04/ pieceOrder
XB2-BA3341DirectionReset(ON)-OFF3A@240VACUS $0.92/ pieceOrder
XB2-BA3351DirectionReset(ON)-OFF3A@240VACUS $0.92/ pieceOrder
XB2-BA42RoundResetON-(OFF)3A@240VAC     US $0.92/ pieceOrder
XB2-BA51RoundReset(ON)-OFF3A@240VAC     US $0.73/ pieceOrder
XB2-BC31MushroomReset(ON)-OFF3A@240VAC     US $0.97/ pieceOrder
XB2-BD21TurnSelf-lockON-OFF3A@240VACVisiting...
XB2-BD23TurnSelf-lockON-ON3A@240VACUS $1.58/ pieceOrder
XB2-BD33TurnSelf-lockON-OFF-ON3A@240VACUS $1.1/ pieceOrder
XB2-BD53TurnReset(ON)-OFF-(ON)3A@240VACUS $1.54/ pieceOrder
XB2-BG21KeySelf-lockON-OFF3A@240VACUS $1.67/ pieceOrder
XB2-BK3363TurnSelf-lockON-OFF-ON3A@240VAC     220V, 24V, 12VUS $2.96/ pieceOrder (3)
XB2-BL31HighReset(ON)-OFF3A@240VAC     US $0.88/ pieceOrder
XB2-BS542Emergency stop3A@240VAC     US $1.04/ pieceOrder
XB2-BW3361RoundReset(ON)-OFF3A@240VAC     220V, 24V, 12VUS $1.65/ pieceOrder (3)
XB2-BW3462RoundResetON-(OFF)3A@240VAC     220V, 24V, 12VUS $1.65/ pieceOrder (3)
XB2-BZ3361XB2-BZ3361Self-lockON-OFF3A@240VAC     220V, 24VUS $2.57/ pieceOrder (2)
▇ General
Model number 22mm XB2-B series
Mounting dimensions φ22
Contact resistance 50mΩ max
Insulation resistance 100MΩ min
Dielectric strength 2000Vac, 50Hz for 1min
Mechanical Life 2x105 cycles
Electrical life 5x104 cycles
Matched contact block NO, NC
IP degree IP40
Operation temperature -25 to 55℃
Operation humidity 35 to 85% RH, no-condensation
Alias name 22mm XB2-B series push button switch, pushbutton
Packaging Details
Product quantity: 1pc
Package weight: 0.15kg
Package size: 10 x 10 x 6 cm
