FMS01-N series micro limit switches
Main child models
Price: US $1.31 / piece
Model number: FMS01-NAW
Product name: Micro limit switch
Product description
▇ Model number and parameters
| Model number | Same model | Operating lever | Matched foot switch | Online store: |
| FMS01-N | 315A | Short spring plunger | FFS01 | Visiting... |
| FMS01-C | 315D | Short spring plunger, with nut | US $1.38/ pieceOrder (6) |
▇ FMS01-N micro limit switch model number legend
▇ General
| Model number | FMS01 |
| Contact form | 2NO |
| Action method | Reset, self-lock |
| Rated voltage (Ue) | 250VAC |
| Rated thermal current (Ith) | 2A |
| External dimensions | 23x12.9 mm |
| Contact resistance | 20mΩ max (initial value) |
| Insulation resistance | 100MΩ min at 500Vdc |
| Dielectric strength | 1500Vac, 50Hz for 1min |
| Machine life | 1x106 operations min |
| Electrical Life | 1x105 operations min |
| Operating temperature | -40-85 ℃ |
| Operating humidity | 35 to 85% RH, no condensation |
| Alias name | FMS01 series push button switch |
▇ FMS01-N micro limit switch child models
| No | Model Number | Action Method | Color | MOQ | Unit Price |
| 1 | FMS01-NAW | Self-lock | White | 1 | US $1.31 |
| 2 | FMS01-NAB | Self-lock | Black | 1 | US $1.31 |
| 3 | FMS01-NAT | Self-lock | Transparent | 1 | US $1.31 |
| 4 | FMS01-NBW | Reset | White | 1 | US $1.31 |
| 5 | FMS01-NBB | Reset | Black | 1 | US $1.31 |
| 6 | FMS01-NBT | Reset | Transparent | 1 | US $1.31 |
FMS01-N series micro switch drawing
FMS01-C series micro switch drawing
