◄ C61F-GP-S12VDC floatless level relay

C61F-GP-P220VAC floatless level relay with without socket and case socket, 220VAC supply voltage

Product features
Mouse over to zoom in
C61F-GP-P220VAC floatless level relay with without socket and case socket, 220VAC supply voltage
Price: US $2.36 / piece
Model number: C61F-GP-P220VAC
DatasheetC61F-GP floatless level relay manual
Product name: Floatless level relay
Socket:
Without socket
US $2.48With socket
US $2.66Without socket and case
US $2.36
Supply voltage:
220VAC
US $2.36110VAC12VDC
Deliver to:
Shipping:
US $7.97via
Estimated Delivery Time: 9-17 days
DDP service: all applicable import duties and taxes are included in total order value.
Quantity:
Total price:US $15.05
Buy Now
Add to Cart
Inquire
Payment:
PayPalCredit CardWESTERN UNIONBANK TRANSFER
Need quotation for reference?Get quotation
Product description
▇ Model number and sensing mode
Model numberSensing modeOnline store:
C61F-GPGeneralVisiting...
▇ C61F-GP floatless level relay model number legend
▇ General
Model number C61F-GP
Rated supply voltage 110, 220Vac, 50/60Hz; 12Vdc
Operational voltage range 85% to 110% of rated voltage
Interelectrode voltage 8Vac
Interelectrode operate resistance 0 to approx. 4kΩ
Interelectrode release resistance Approx. 15 k to ∞Ω
Response time Operate: 80 ms max; Release: 160 ms max.
Contact rating 5A at 250Vac
Matched socket PF083A
Matched probe FFRA01
Life expectancy Mechanical—5x106; Electrical—1x105
Insulation resistance 100 MΩ min. (at 500 Vdc)
Dielectric strength 1500Vac, 50/60 Hz for 1 min
Power consumption Approx. 3.2 VA max
Cable length 1Km max
External dimensions (HxWxD) 61x49x70mm
Operational Temperature -10 to +55°C
Operational humidity 85% RH max
Alias name C61F-GP floatless level controller
▇ C61F-GP floatless level relay submodels
No Model Number Socket Supply Voltage MOQ Unit Price Related Product
1 C61F-GP-N220VAC Without socket 220VAC 1 US $2.48 Order
2 C61F-GP-N110VAC Without socket 110VAC 1 US $2.48 Order
3 C61F-GP-N12VDC Without socket 12VDC 1 US $2.48 Order
4 C61F-GP-S220VAC With socket 220VAC 1 US $2.66 Order
5 C61F-GP-S110VAC With socket 110VAC 1 US $2.66 Order Unfold
6 C61F-GP-S12VDC With socket 12VDC 1 US $2.66 Order
7 C61F-GP-P220VAC Without socket and case 220VAC 3 US $2.36 Visiting...
C61F-GP wiring example
Packaging Details
Product quantity: 3PCS
Package weight: 0.13kg
Package size: 10 x 10 x 7 cm
