STC-9200 series cooling defrosting fan temperature controllers
Main child models
Price: US $9.89 / piece
Model number: STC-9200-220VAC
Product name: Cooling defrosting fan temperature controller
Product description
▇ Model number and parameters
| Model number | Main function | Online store: |
| STC-9200 | Cooling, defrosting, fan, dual sensors, temperature overrange and sensor fault alarms | Visiting... |
▇ STC-9200 cooling defrosting fan temperature controller model number legend
STC-9200
Parent Model Number
▇ General
| Model number | STC-9200 |
| Measure range | -50 to 90 ℃ |
| Setting range | -50 to 50 ℃ |
| Resolution | 0.1 ℃ |
| Accuracy | ±1 ℃ (-40 to 50 ℃), ±2 ℃ (50 to 70 ℃) |
| Supply voltage | 220Vac, 110Vac, 50/60Hz; 12Vac/dc, 24Vac/dc |
| Power consumption | Less than 5W |
| Output types | Three mechanical relays |
| Input types | 2pcs 2m cable NTC (included) |
| Panel size | 75x34.5 mm |
| External dimensions | 75x34.5x85 mm |
| Perforation dimensions | 71 10x29 10 mm |
| Control method | ON/OFF Control |
| Setting method | Touch switch |
| Indication method | Three-digit LED + Minus digit + Status indicator light (set; refrigeration; defrost; fan) |
| Front panel IP Rating | IP65 |
| Operating temperature | 0 to 55 ℃ (32 to 131 ℉) |
| Operating humidity | 20% to 85% RH, non-condensing |
| Storage temperature | -25 to 75 ℃ (-13 to 167 ℉) |
| Alias name | STC-9200 freezer temperature controller, defrost thermostat, freezer thermostat |
▇ Output type and description
| Electromagnetic relay for compressor | Contact rating: 8A at 220Vac |
| Electromagnetic relay for fan | Contact rating: 8A at 220Vac |
| Electromagnetic relay for defrosting | Contact rating: 8A at 220Vac |
▇ STC-9200 cooling defrosting fan temperature controller child models
| No | Model Number | Supply Voltage | MOQ | Unit Price |
| 1 | STC-9200-220VAC | 220VAC | 1 | US $9.89 |
| 2 | STC-9200-110VAC | 110VAC | 1 | US $10.79 |
| 3 | STC-9200-24V | 24VAC/DC | 1 | US $9.89 |
| 4 | STC-9200-12V | 12VAC/DC | 1 | US $9.89 |
